Specifications

• Designed for smooth operation, Plug and Play no settings required.
• Protection : Thunder Lightning - anti static and anti - interference ability up to 6KV.
• 2 Ports X 1000 Mbps uplink Ethernet port (Extra Port to connect Internet / Existing Network
• 16 Ports X 100 Mbps downlink PoE (Power over Ethernet) every port supports MDI / MDX.
• Standard : Meet IEEE802.3 , IEEE802.3u , IEEE802.3 af/ at standards, Support MID - Span & END - Span Devices.
• One Key CCTV / VLAN mode (All Downlink Ports can communicate with uplink ports only , it makes system more secure).
• Transmission Distance : Ethernet 0 ~ 100m.
• The furthest transmission distance can be reach 250 Meters in CCTV & VLAN mode uplink port can reach 100m.
• Operating status can be analyzed through corresponding LED indicators on each port.
• Ideal for multi-stream cameras that required high bandwidth.
• Compatibility with network devices from other vendors.
• MAC address auto-learning and auto-aging.
• Metal case with desktop or wall-mounting design.
• Built in power Supply.
• Auto detect power devices (PD).
• Store and forward switching method.
• Switching Capacity - 9Gbps.
• Forwarding Rate - 9Mpps (Million Packets Per Second).

 Application

• Video Surveillance
• IP Phone
• Access Points
• Public Address Systems
